Capella
Chafe-Protection
Capella Chafe-Protection features protective covering listed for use with mooring ropes and round slings. Compare the source dimensions and confirm the cover required for your application.
- Product family
- Marine Chafe Protector
- Industry
- Commercial Marine
Available by quotation
Request a quote
View technical specifications
Non-stocked product. Tell us your specifications and we will confirm pricing, configuration and lead time.
Capella / Available by quotation
Tell us what you need.
Start with your application and required dimensions. Our team will review the configuration before providing a quotation.
Prefer email? mike@ropehub.com
Breaking-load values are not working load limits. Application suitability, dimensions and end terminations must be confirmed before ordering.
Product details & technical data
Breaking-load values are not working load limits. Application suitability, dimensions and end terminations must be confirmed before ordering.
Rope and sling chafe protection
Capella Chafe-Protection features protective covering listed for use with mooring ropes and round slings. Compare the source dimensions and confirm the cover required for your application.
Request a quote with the rope diameter, required cover length and quantity. This is a non-stocked item; fit, price and lead time require confirmation.
Overview
As method of perfect protection could be applied to mooring rope as well as round sling. Chafe-protection will prevent mooring rope as well as round sling from abrasion and the life time of ropes and sling will be longer with perfection.
Construction, Features and Applications
Features:
Longer life time of mooring rope & s round sling is guranteed.
High abrasion resistance.
Bespoke diameter and length is available.
Applications: Mooring rope. Round sling.
Technical Specifications
Item Number |
For Rope Diameter(mm) |
For Rope Diameter(inches) |
For Spliced Rope Diameter(mm) |
For Spliced Rope Diameter(inches) |
6341011 |
24 - 38 |
1 - 1-1/2 |
12 - 20 |
1/2 - 3/4 |
6341021 |
40 - 56 |
1-5/8 - 2-1/4 |
22 - 32 |
7/8 - 1-1/4 |
6341031 |
60 - 76 |
2-3/8 - 3 |
34 - 38 |
1-5/16 - 1-1/2 |
Breaking-load values are not working load limits. Diameter, length, end termination, and application suitability require confirmation before ordering.
Technical Reference
Original manufacturer documents are retained for technical reference and may show the original manufacturer's branding. Specifications require confirmation for the requested configuration.
Request a Quote
This is a quote-only, non-stocked product. Please request a quotation for your required diameter, length, quantity, terminations, and application. Pricing, availability, and lead time are confirmed with the quotation.
