Armbury Domain AG D-Shaped Triple-Lock Carabiner

Armbury Domain AG D-Shaped Carabiner

The Armbury Domain AG is a large, D-shaped aluminum carabiner with a triple-lock gate for anchors and rigging. Its directional frame keeps loads along the major axis, while the 28 mm gate opening and keylock nose help make clipping ropes and webbing straightforward.

Strong, practical anchor connections

When building an anchor or arranging rigging components, the Domain AG provides room to clip and a shape designed for efficient major-axis loading. A lock marking offers a visible warning when the gate is unlocked, and the keylock nose helps avoid snagging during handling.

Key features

• Large D-shaped light-alloy carabiner designed for anchors and rigging
• Triple-lock gate with unlocked-gate visual marking
• 28 mm gate opening and keylock nose for easier clipping of ropes and webbing
• Individually tested to 10 kN and assigned a unique serial number for traceability, according to the supplied technical sheet

Size and related gate versions

• Domain AG dimensions: 120 × 77 mm
• This model: triple lock, manufacturer reference 4131334
• Other Domain versions listed by the manufacturer:
  • screw lock (4131314) and
  • twist lock (4131324).

Technical specifications

• Dimensions: 120 × 77 mm
• Gate opening: 28 mm; gate: triple lock
• Minimum breaking strength, major axis: 30 kN
• Minimum breaking strength, minor axis: 10 kN
• Minimum breaking strength, gate open: 8 kN
• Material: aluminum
• Weight: 87 g/m

Certification & safety

The supplied technical sheet lists CE, EN 12275, EN 362 and UIAA. Check the markings on the item and follow current manufacturer instructions for approved uses, gate operation, compatibility, inspection and retirement. Verify the gate is locked before loading; strength ratings vary with loading direction and gate condition.
